Treated right. Filtered clean.
Authorized distributor of Kurita chemicals and of Xylem side stream filtration for Southeast Asia.
What side stream filtration prevents
Design basis · 5–10% of recirculation flow · returned to basin
Automatic self-cleaning screen filter: VAF™ V-Series
VAF™ V-200 self-cleaning screen filter
The V-200P flushes itself automatically in 10–15 s when differential pressure reaches 0.5 bar, using about 15 L per flush and stays online throughout. Its water motor drive needs no electrical power for cleaning.
- Flow
- 7–50 m³/h per filter (varies with micron)
- Nominal
- 30 · 36 · 44 · 50 m³/h at 50 · 80 · 100 · 120+ µm
- Screens
- 10–1500 micron, 316L SS sintered weave-wire
- Flush
- Automatic, 10–15 s at 0.5 bar ΔP · 15 L per flush
- Online
- Stays in service while flushing
- Power
- None: water motor drive runs on line pressure
- Pressure
- 2–8 bar · max 40 °C
- Body
- Glass-reinforced nylon · 3″ BSP/NPT/grooved inlet/outlet · 1.5″ flush outlet
- Control
- MicroFlush™ controller, up to four filters
VAF™ V-1000 self-cleaning screen filter
The V-1000 handles 14–374 m³/h per filter in a 316L stainless steel body. It flushes automatically in 12–15 s when differential pressure reaches 0.5 bar, using about 57 L per flush and stays online throughout.
- Flow
- 14–374 m³/h per filter (varies with micron)
- Nominal
- 242 · 325 · 356 m³/h at 100 · 200 · 300 µm
- Screens
- 10–1500 micron, 316L SS sintered
- Flush
- Automatic, 12–15 s at 0.5 bar ΔP · 57 L per flush
- Online
- Stays in service while flushing
- Pressure
- 2–10 bar · max 80 °C
- Body
- 316L SS · 6″ or 8″ inlet/outlet · AWWA Class D flanges
- Control
- MicroFlush™ controller, up to four filters
How fine each filter goes
Which filter fits my system?
| VAF™ V-200 | VAF™ V-1000 | |
|---|---|---|
| Flow range | 7–50 m³/h per filter | 14–374 m³/h per filter |
| Micron rating | 10–1500 micron, 316L SS sintered screens | 10–1500 micron, 316L SS sintered screens |
| Footprint | Compact inline · 3″ inlet/outlet · 1.5″ flush outlet | 164.6 cm long · 6″ or 8″ flanged inlet/outlet |
| Power need | None: runs on line pressure | MicroFlush™ controller, up to four filters |
| Typical application | Cooling towers and closed loops, small to mid recirculation flows | Larger cooling tower and process flows |
{{ ch.t }}
{{ ch.d }}
Any chemical in the Kurita portfolio can be sourced and supplied through Oasis. Ask us.
Questions buyers ask us.
{{ f.q }}
{{ f.a }}
Tell us about your system.
Send your system type and recirculation flow rate and an Oasis engineer will come back with a chemical programme, a filter size or both.
